MechMaxx · NAM · ReviewUpdated 2026-08-05
MechMaxx NAM60 review
The NAM60 is the standard MechMaxx step up from EFS: a 60″ Cat 1 hammer flail with 1.8 lb hammers, a 5″ rotor, and no hydraulic side shift.
Pros and cons
Pros
- Heavier 1.8 lb hammers than the EFS line
- 595 lb machine weight is manageable for many utility compacts
- Lower sale price than premium 55–62″ factory-direct alternatives
Cons
- No hydraulic side shift or ditch-bank tilt
- Hammer-only rotor with no Y-blade finish option listed
- 1-year warranty and direct-manufacturer support path
01What the NAM60 actually is
MechMaxx lists NAM60 at 60″ cutting width, 65″ overall width, 30–60 HP, Category 1 hitch, 595 lb machine weight, and 662 lb shipping weight. It is the small standard NAM deck, not the light EFS platform.
The deck is fixed rather than hydraulic side shift. No rear remotes are required, and buyers who need lateral reach should compare NAM68H/NAM72H or Woodmaxx H models instead.
02Cutting package and driveline
Verified specs include a 0.6″–2″ cutting-height range, 24 hammers at about 1.8 lb each, 5″ rotor, 14″ blade swing, 4″ rear roller, and three 17x991 belts.
MechMaxx lists a T6-LF-39 shear-bolt PTO shaft. Treat the NAM60 as a hammer-only rough-mowing value deck; there is no published Y-blade finish option.
03Value vs EFS60 and Woodmaxx FM-62
Against EFS60, NAM60 costs more and weighs more, but buys the heavier NAM hammer package and 30–60 HP positioning. It is the better fit when the job is rougher than light grass and weeds.
Against Woodmaxx FM-62, NAM60 is cheaper and wider on paper, while Woodmaxx counters with a 2-year warranty, hammer/Y-blade ordering options, and a stronger support story. MechMaxx is a direct manufacturer link here, not an affiliate offer.
What's in the box
- NAM60 flail mower deck with 24 hammers
- Category 1 fixed NAM three-point mounting
- T6-LF-39 shear-bolt PTO driveline
- 3× 17x991 belt drive with tensioner
- 4″ rear roller
- Tractor with Category 1 three-point hitch and 540 RPM PTO
- Rear hydraulic remote pair (not used on this fixed model)
- Front ballast or loader weight as needed for a 595 lb mower
- Y-blade kit or alternate finish blade setup
- No hydraulic side shift is listed for NAM60.
- Check gearbox oil, PTO shaft length, belt tension, and hammer hardware before first use.
Full specifications
Normalized from manufacturer data (verified 2026-08-05). Always confirm on the current product page before you order.
- Brand
- MechMaxx
- Model
- NAM60
- Cutting width
- 60″
- Overall width
- 65″
- PTO horsepower
- 30–60 HP
- Min HP per foot of cut
- 6.00
- Hitch
- Category 1
- Offset
- Fixed offset
- Side-shift detail
- Fixed Cat 1 NAM mount; no hydraulic side shift.
- Rear remotes required
- 0
- Machine weight
- 595 lb
- Shipping weight
- 662 lb
- Cutting height
- 0.6″–2″
- Rotor diameter
- 5″
- Rotor RPM
- Not published
- Blade swing diameter
- 14″
- Blade tip speed
- Not published
- Hammer blades
- 24 × 1.8 lb (43.2 lb total)
- Blade options
- hammer
- Belts
- 3 × V 17x991
- PTO / driveline
- 1-3/8″ Z6 shear-bolt PTO shaft T6-LF-39
- Drive notes
- 3× 17x991 belts with tensioner, 5″ rotor, 14″ blade swing, 4″ rear roller, shear-bolt PTO driveline; no hydraulic shift
- Price (list)
- $2,299
- Warranty
- 1 year
- Specs verified
- 2026-08-05
Tractor compatibility
- Match PTO horsepower to 30–60 HP. Use PTO HP from the tractor manual, not engine HP. Published mins in this catalog are all at least 3.0 HP per foot of cut.
- Machine weight is about 595 lb (shipping ~662 lb) — confirm your tractor’s 3-point lift capacity with margin for the PTO shaft and terrain.
- Hitch requirement: Category 1.
- No rear remotes required for cutting. A standard 540 RPM PTO and matching hitch is enough.
- Ballast the front end on steep or soft ground, especially with wider decks (60″).
Who should buy the NAM60, and who should skip it
30–60 HP tractor owners who want a heavier standard flail than the EFS60 for open acreage, but do not need hydraulic offset or Woodmaxx blade/support extras.
You want a standard 60″ NAM deck
The 5″ rotor and 1.8 lb hammers are a meaningful step above the light EFS series.
Your tractor fits 30–60 HP Cat 1
NAM60 is aimed at compact/utility tractors with enough lift for a 595 lb machine.
You do not need side shift
Zero rear remotes and a fixed deck keep setup simpler.
You need hydraulic reach
Choose NAM68H/NAM72H or a Woodmaxx H model for side shift.
You want the lowest 60″ price
EFS60 is cheaper, lighter, and more light-duty.
You want Y-blades or a longer warranty
Woodmaxx FM-62 is the cleaner comparison when support and blade choice outweigh price.
Alternatives to consider
Accessories worth planning for
Front ballast / loader ballastOptional
Worth checking before lifting a 595 lb mower on compact-tractor terrain.
Spare 17x991 belt setOptional
NAM60 uses three 17x991 belts; stock a matched set if acreage downtime matters.
Replacement 1.8 lb hammer kitOptional
Wear parts for the 24-hammer rotor; inspect hardware after debris or rough mowing.
Shear bolts and PTO toolsOptional
The T6-LF-39 driveline uses shear-bolt protection, so keep correct replacements on hand.
Hammers vs Y-blades
Heavy hammer blades
24 hammers · ~1.8 lb each
Best for: Open grass, weeds, and rougher mowing than the EFS light-duty line
Finish: Mulched / utility finish
The NAM60 is published as hammer-only; no Y-blade finish option is listed.
Hammer-only published configuration. Compare Woodmaxx FM-62 if an order-time Y-blade setup is important.
What buyers should know about the NAM60
Themes are editorial interpretations from manufacturer-published specs and brand-level MechMaxx value discussions (retrieved 2026-08-07). Model-specific owner volume is thin.
- Step up from EFS. NAM60 is positioned as the move from EFS light-duty specs to a heavier rotor and hammer package.
- No hydraulic complexity. Zero rear remotes simplifies setup but limits fence-line reach versus NAM-H.
- Value vs Woodmaxx. Lower direct price is balanced against Woodmaxx blade choices and longer warranty positioning.
- Hammer-only setup. Published configuration is hammer-only, so finish-blade flexibility is not part of the pitch.
Detailed specifications & features
MechMaxx lists NAM60 at 60″ cutting width, 65″ overall width, 30–60 HP, Category 1 hitch, 595 lb machine weight, and 662 lb shipping weight. It is the small standard NAM deck, not the light EFS platform.
Verified specs include a 0.6″–2″ cutting-height range, 24 hammers at about 1.8 lb each, 5″ rotor, 14″ blade swing, 4″ rear roller, and three 17x991 belts.
60″ NAM-series hammer flail with a heavier 5″ rotor package than EFS and no hydraulic side shift.
Key features
- +30–60 HP Category 1 tractor range
- +595 lb machine weight and 662 lb shipping weight
- +Fixed standard NAM mount with zero rear remotes required
- +24 hammers at approximately 1.8 lb each
Manufacturer-published specs
- SKU
- 150137
- Sale price
- $2,299
- Regular price
- $2,699
- Cutting width
- 60 in
- Overall width
- 65 in
- PTO horsepower
- 30–60 HP
- Hitch type
- Category 1
- Machine weight
- 595 lb
- Shipping weight
- 662 lb
- Cutting height
- 0.6 – 2 in
- Blade count
- 24 hammer blades
- Hammer weight
- Approximately 1.8 lb each
- Rotor
- 5 in tube
- Blade swing diameter
- 14 in
- Side shift
- Fixed standard NAM mount; not hydraulic
- PTO
- 1-3/8″ Z6 shear-bolt PTO shaft T6-LF-39
- Drive belts
- 3× V 17x991
- Warranty
- 1 year
Specifications sourced from the manufacturer’s product page on August 5, 2026. Specs may change without notice.
FAQ
What tractor size fits the MechMaxx NAM60?+
MechMaxx lists NAM60 for 30–60 HP Category 1 tractors. Machine weight is 595 lb and shipping weight is 662 lb.
How wide is the NAM60?+
The verified cutting width is 60″ and overall width is 65″.
Does NAM60 have hydraulic side shift?+
No. NAM60 is a fixed standard NAM mower with zero rear remotes required.
What blades come on NAM60?+
MechMaxx lists 24 hammers at about 1.8 lb each. No Y-blade option is listed for this SKU.
What belts and PTO shaft does NAM60 use?+
Verified specs list three 17x991 belts and a T6-LF-39 shear-bolt PTO shaft.
NAM60 vs EFS60, which should I buy?+
Buy NAM60 for the heavier 5″ rotor and 1.8 lb hammers. Buy EFS60 for lower price, lighter weight, and light-duty grass/weeds.
NAM60 vs NAM68, which should I buy?+
NAM68 adds 8″ of cut, more hammer count, and more weight. NAM60 is easier to lift and place if 60″ is enough.
NAM60 vs Woodmaxx FM-62, which should I buy?+
NAM60 is the lower-price MechMaxx direct option. Woodmaxx FM-62 offers a 2-year warranty, blade choice, and stronger support positioning.
What warranty does the NAM60 include?+
MechMaxx publishes a 1-year warranty on machines (separate engine warranties may apply on some powered products). Against Woodmaxx FM models (2-year parts), that shorter term is the main support tradeoff for MechMaxx's lower sticker. Confirm the current machine warranty and claim path on the MechMaxx site before you buy; coverage language is thinner than Woodmaxx's published parts process.
